Adjustable Steel Formwork Construction Reusable Concrete Wall Formwork Systems For Variable Wall Thickness

Brand Name : WKS

Certification : ROHS

Place of Origin : Hebei,China

MOQ : 50 piece

Price : US $90.00 - 110.00/ Square Meter

Payment Terms : T/T

Supply Ability : 1000 piece in 10 days

Delivery Time : 10-30 workday

Packaging Details : Bundled / Tied in bundles/Optimization of container loading

Product name : Steel Formwork Construction

Material : Steel Frame: Q235

Feature : Reusable, High Strength, adjustable size

Colour : green, blue, orange, yellow or customized

Type : Wall Form

Thickness of front panel : 12mm,15mm

Column bearing capacity : 80KN/sqm

Width : 300-2400mm

Height : 600mm,1200mm,1500mm,2400mm,2700mm,3300mm or customized

Frametype : Rectangular or square

Contact Now

Adjustable Steel Frame Formwork System for Variable Wall Thickness Design

Steel Frame Formwork is a heavy-duty modular system engineered for high-rise buildings, bridges, and infrastructure projects. It combines a rigid steel frame with replaceable high-density panels to deliver superior strength, precision alignment, and fast cycle times under high concrete pressure.

Features & Functions

High Load Capacity: Designed to withstand fresh concrete pressures up to 60-80 kN/m², ensuring minimal deflection and perfect verticality for tall walls and columns.
Fast Clamp Connection: Features quick-lock clamps and alignment couplers instead of bolts, enabling rapid assembly and disassembly without specialized tools, cutting labor time.
Modular Flexibility: Standardized panel sizes (e.g., 600/900/1200mm widths) allow versatile configurations for various layouts, reducing on-site cutting and waste.
Crane-Handling Optimized: Integrated lifting points and robust frames are designed for efficient crane handling and positioning of large panels, streamlining workflow.

Key Specifications

Frame: 4-6mm thick steel, hot-dip galvanized or powder-coated
Panel: 18mm/21mm Film Faced Plywood (Birch/Hardwood core)
Standard Sizes: 600/900/1200mm (W) x 2400/2700/3000mm (H)
System Weight: ~45-65 kg/m²
Max Reuse: 100+ cycles (frames), 30-50 cycles (panels)

Competitive Advantages

Lowest Lifetime Cost: The galvanized steel frame lasts for hundreds of cycles with only inexpensive panel replacement, offering superior ROI over plastic or aluminum systems.
Industrial-Grade Reliability: The preferred solution for contractors needing absolute structural integrity for critical infrastructure and high-pressure pours.
Global Standard Compatibility: Compatible with major international system accessories, ensuring easy integration and parts availability on global job sites.

Specifications & Features

Materials	Steel Frame: Q235, Q345 Panel: Poplar/Birch/Hardwood with domestic or imported film faced paper
Thickness of Front Panel	12mm, 15mm
Color Options	Green, blue, orange, yellow or customized
Surface Treatment	Hot Dip Galvanized (HDG); cold galvanized; powder coated; dip painted
Column Bearing Capacity	80KN/sqm
Wall Bearing Capacity	60KN/sqm
Height Options	600mm, 1200mm, 1500mm, 2400mm, 2700mm, 3300mm or customized
Width Range	300-2400mm
Weight Range	Approximately 20KG-350KG

Application Scope

Suitable for residential and commercial buildings, concrete tanks, basements, bridge abutments and piers, and irregular concrete structures.

Professional Services

Customized Production Services

Our team assists with customized product configurations based on your project's architectural and structural drawings. Professional engineers and consultants provide detailed application solutions to ensure smooth implementation.

Responsive Technical Support

Professional engineers are available throughout pre-sales, during implementation, and post-sales to promptly address and meet your requirements. Our engineering team provides reasonable suggestions for your application plans.

Comprehensive After-Sales Service

Dedicated one-on-one service teams help complete engineering project implementation. Independent service teams for each project ensure perfect product-demand matching and efficient on-site construction.

Adjustable Steel Formwork Construction Reusable Concrete Wall Formwork Systems For Variable Wall Thickness

Frequently Asked Questions

Do you provide samples? Is the sample chargeable or free?

Yes, we provide small size samples. Larger samples may require payment, and shipping costs are typically the customer's responsibility.

Are you a trading company or a manufacturer?

We are a subsidiary foreign trade company of a group company, responsible for exporting formwork and scaffolding products. Our group operates two major production bases with over 20 years of specialized manufacturing experience.

How to get quotation?

For simple concrete pouring projects with your own engineer, provide a bill of materials for quotation. For complex projects like apartments and villas, our consultants will develop application plans based on your architectural and structural drawings.

What can we supply for you?

We offer a comprehensive range of scaffolding, formwork accessories, and safety products for construction industries. We also design and produce custom steel items according to client specifications.

How can you guarantee better service and high quality products?

Advanced automated production lines, experienced workers, quality inspection teams, and chemical/physical laboratories ensure high quality. Our engineering team provides technical support, and sales teams offer responsive communication through various platforms.

How long is the estimated delivery time after the contract is signed?

Typically 30-60 days for completion, depending on project complexity. More accurate delivery timelines are provided during the planning and quotation process.

What is your terms of payment?

T/T with 30% deposit before manufacture and 70% balance payment against B/L copy, or L/C arrangements.
